Arashi KBT N54 135i 535i 535xi Z4 LHD+RHD / 335i RHD Twin Turbo TD04L-19T 6cm Ball Bearing

Application:

BMW135i / 135is (E82/E88) N54 3.0L Turbo, 2008 – 2013

BMW535i / 535xi (E60/E61) N54 3.0L Turbo, 2004 – 2010

BMW Z4 sDrive35i / Z4 sDrive35is(E89 Z4) N54 3.0L Turbo, 2009 – 2016

N54 is a twin-turbocharged engine, one front turbo and one rear turbo. Kindly note that there are two different types of rear turbos which we call Rear and Rear2. The location you bought the car from decides whether your N54 comes with Rear or Rear2 turbo, their compressor housings and positions are different. Before purchasing N54 upgraded turbos from us please specify which rear turbo do you have from factory, consult with us if you do not know how to distinguish them.

Compressor Wheel:

46 / 58 mm (6+6 Blades Billet 19T)

Turbine Wheel:

41.2 / 47 mm (High Flow 9BladesTD04L Performance High Inconel)

Compressor Housing:

2″ Compressor inlet

Turbine Housing:

6cm^2 / 0.41 AR

Bearing:

Dual-row ceramic ball bearing

Includes:

1 x N54 twin turbo with manifold

1 x Oil feed line & return line kit

6 x Manifold gasket

Description:

Arashi Performance is professional Japanese racing parts manufacturers.

Brand New and Complete CHRAs balanced by VSR Core-Balancing Machine from Turbo Technics. Balance sheet will go with the turbo.

*Contact usFor any inquiries or special requests such as larger amount ordering
